Bookings Database: table structure and schema overview
The Bookings database (PostgreSQL) models airline flights across multiple airports and is widely used for SQL practice.
This page shows the table structure, key columns, and constraints used in typical analytical and transactional SQL queries.
The Bookings database contains 8 main tables.
ER diagram of the Bookings database
More about the Bookings database: schema, sample queries and all exercises →
The list of tables
aircrafts_data - table of aircrafts.
- aircraft_codeUnique code for each aircraft
- modelAircraft model name in English and Russian in JSON format
- rangeAircraft fly range in kilometers
- PRIMARY KEY, btree (aircraft_code)
| aircraft_code | model | range |
|---|
| 1 | 773 | {"en": "Boeing 777-300", "ru": "Боинг 777-300"} | 11100 |
airports_data - table of airports.
- airport_codeUnique code for each airport
- airport_nameAirport name in English and Russian in JSON format
- cityAirport city in English and Russian in JSON format
- coordinatesAirport coordinates as POINT(longitude, latitude)
- timezoneAirport timezone name
- PRIMARY KEY, btree (airport_code)
| airport_code | airport_name | city | coordinates | timezone |
|---|
| 1 | YKS | {"en": "Yakutsk Airport", "ru": "Якутск"} | {"en": "Yakutsk", "ru": "Якутск"} | (129.77099609375,62.0932998657227) | Asia/Yakutsk |
boarding_passes - table of boarding passes.
- ticket_noTicket number
- flight_idFlight identificator
- boarding_noBoarding pass number
- seat_noSeat number
- PRIMARY KEY, btree (ticket_no, flight_id)
- UNIQUE CONSTRAINT, btree (flight_id, boarding_no)
- UNIQUE CONSTRAINT, btree (flight_id, seat_no)
- FOREIGN KEY (ticket_no, flight_id) REFERENCES ticket_flights(ticket_no, flight_id)
| ticket_no | flight_id | boarding_no | seat_no |
|---|
| 1 | 0005435212351 | 30625 | 1 | 2D |
bookings - table of bookings.
- book_refBooking number
- book_dateBooking date
- total_amountTotal booking cost
- PRIMARY KEY, btree (book_ref)
| book_ref | book_date | total_amount |
|---|
| 1 | 00000F | 2017-07-05 00:12:00+00 | 265700.00 |
flights - table of flights.
- flight_idFlight ID
- flight_noFlight number
- scheduled_departureScheduled departure time
- scheduled_arrivalScheduled arrival time
- departure_airportAirport of departure
- arrival_airportAirport of arrival
- statusFlight status
- aircraft_codeAircraft code, IATA
- actual_departureActual departure time
- actual_arrivalActual arrival time
- PRIMARY KEY, btree (flight_id)
- UNIQUE CONSTRAINT, btree (flight_no, scheduled_departure)
|
flight_id |
flight_no |
scheduled_departure |
scheduled_arrival |
departure_airport |
arrival_airport |
status |
aircraft_code |
actual_departure |
actual_arrival |
|---|
| 1 | 1185 | PG0134 | 2017-09-10 06:50:00+00 | 2017-09-10 11:55:00+00 | DME | BTK | Scheduled | 319 | | |
seats - table of aircraft seats.
- aircraft_codeAircraft code, IATA
- seat_noSeat number
- fare_conditionsTravel class
- PRIMARY KEY, btree (aircraft_code, seat_no)
- FOREIGN KEY (aircraft_code) REFERENCES aircrafts(aircraft_code) ON DELETE CASCADE
|
aircraft_code | seat_no | fare_conditions |
| 1 | 319 | 2A | Business |
ticket_flights - ticket to flights relations.
- ticket_noTicket number
- flight_idFlight ID
- fare_conditionsTravel class
- amountTravel cost
- PRIMARY KEY, btree (ticket_no, flight_id)
- FOREIGN KEY (flight_id) REFERENCES flights(flight_id)
- FOREIGN KEY (ticket_no) REFERENCES tickets(ticket_no)
|
ticket_no |
flight_id |
fare_conditions |
amount |
| 1 | 0005432159776 | 30625 | Business | 42100.00 |
tickets - table of tickets.
- ticket_noTicket number
- book_refBooking number
- passenger_idPassenger ID
- passenger_namePassenger name
- contact_dataPassenger contact information
|
ticket_no |
book_ref |
passenger_id |
passenger_name |
contact_data |
| 1 | 0005432000987 | 06B046 | 8149 604011 | VALERIY TIKHONOV | {"phone": "+70127117011"} |
- PRIMARY KEY, btree (ticket_no)
- FOREIGN KEY (book_ref) REFERENCES bookings(book_ref)
